KRX 1000 Forged piston, rod and head stud kit for BOOST!
Part #M3040 92mm stock bore 9.5:1 CR turbo pistons
The pistons are manufactured from forged 2618 alloy for added structural support, strength and durability. These Teryx pistons include all of the company’s engineering enhancements, including anti-detonation grooves (turbo application), accumulator groove, pick lock grooves and double force-fed pin oilers with reservoir groove, precision pin fitting and custom cam profiles. All piston kits include rings, wrist pins and locks. All rods are supplied with CARR fasteners for maximum reliability and clamping force.
The Teryx rods are made from USA-made forgings and incorporate CP-Carrillo’s H beam design. Both pistons and rods are available off the shelf and include custom features incorporating CP-Carrillo high standards and consistent quality.
BC6941 - Kawasaki KRX (20-up) ProH2K Connecting Rods w/ARP2000 Fasteners
Kawasaki Teryx KRX - ProH2K w/ARP2000 Fasteners. Made from aerospace grade, 4340 chromoly steel, BC high performance connecting rods deliver the reliability required for high rpm applications. Every rod is CNC machined, micro polished surface finish treatment, equipped with Aluminum/Silicone/Bronze pin bushings and finish honed to exacting tolerances.
K361-18-0100 - Kraftwerks Head Stud kit
Kraftwerks Off-Road Head Stud Kits are recommended for all high-compression and force induction UTV engines. Even on stock engines, Kraftwerks Off-Road Head Studs offer additional protection from blown head gaskets when pushing engine performance. Kraftwerks Off-Road Head Studs are machined from 4140 alloy steel and are specially heat treated to achieve a tensile strength of 220,000psi+. Each kit comes complete with head studs, washers, nuts, anti-seize compound, and simple to follow instructions.
